Product Details:
|
| Private Mold: | Yes | Style: | Other |
|---|---|---|---|
| Communication: | Wired | Use: | Power Supply |
| Material: | Metal, Plastic | Function: | Power Supply |
| Polar Pattern: | Omni-directional, Cardioid, Figure-8, Hypercardioid | Type: | Condenser Microphone, XLR-USB TYPE-C |
| Signal To Noise Ratio: | 75dB | Frequency Response Rate: | 20Hz-20KHz |
| Maximum SPL: | 125DB | Sensitivity: | -36dB±2dB |
| Product Name: | Professional Microphone Power Supply | Model: | PSU100 |
Microphone Power Supply Studio recording Vlog Broadcasting Condenser Gaming Microphone USB for streaming
797Audio XLR to USB Phantom Power Supply For Professional Microphone
Phantom power is a device that supplies powers for a capacitor microphone.In the capacitor microphone,a certain voltage is needed for polar plates of the capacitor head to build the electric field to work(the electret microphone has a built-in polarized electric field ,no phantom power is needed),and the microphone amplifier(also known as a preamplifier) in the capacitor microphone also needs power supply.Thus the main function of the phantom power supply is provide power to the microphone amplifier and the capacitor head in the capacitor microphone.
Instruction
1.Turn on the power switch and the power indicator on the switch is on.
2.Plug the female XLR into the dock connector for microphone ,while plug the male XLR into the dock connector for microphone input jack of the phantom power.
3.Plug another female XLR into the signal input dock of the phantom power ,while plug the other end of XLR into the mixer ,sound card or device with balance input.
| Product | Microphone Power Supply |
| Model | PSU100 |
| Brand | 797AUDIO |
| Power Supply Type | Type C USB Power Supply(5V) |
| Output Voltage | 48±4V |
| Max Output Current | 10.2mA |
| Size | 122*90*44 mm |
| Weight | 290g |
| Supply Service | 797Audio Brand,OEM,ODM |
| Delivery Terms | By sea, By Express,By Air, By Train |
| Applications | Interview, Live Chat, Recording, Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc. |
Power Supply for XLR Professional Recording Microphone
Interview, Live Chat, Recording, Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc.
Beijing 797 Audio Co.,Ltd. was founded in 1953 as an electric-acoustic manufacturer with long history in the field of microphone,speaker system,audio,etc.
Beijing 797 Audio Co., Ltd. has set microphone, speaker national standard, industry standard for audio, It covers audio products, public broadcasting and other fields. We already get over 70 patents on microphones and loudspeakers. We get ISO9001,ISO14001,ISO45001,and CE certificates, And our products have also been winning awards continuously.
