Product Details:
|
| Private Mold: | Yes | Style: | Headset Microphone, Handheld Microphone, Gooseneck Microphone, Lavalier Microphone, Desktop, Shock Mount, Wired Microphone, Handheld Microphone With Speaker, Podcasting Sound Card |
|---|---|---|---|
| Communication: | Wired | Use: | COMPUTER MICROPHONE, Conference Microphone, Karaoke Microphone, Church, Stage Performance, INTERVIEW, Speech, Smart Phones, Recording, SINGING, Teaching, Portable Audio Player, Communication, Broadcasting, Kids, Gaming |
| Material: | Metal | Function: | Noise Cancelling, Light-weight, PORTABLE, Condenser Microphone, With RGB Lighting, With Sound Card |
| Polar Pattern: | Cardioid, Cardioid | Type: | Condenser Microphone |
| Frequency Response Rate: | 20Hz-20KHz | Maximum SPL: | 137db |
| Sensitivity: | -38dB(0dB=1V/Pa,1kHz) | Product Name: | Professional Condenser Microphone |
| Brand: | 797Audio | Model No.: | ACCR01 |
| Sensitivity(dB)(1000Hz): | -38dB(0dB=1V/Pa,1kHz) | Recommended Load Impedance: | Above 1000 Ohms |
| Frequency Range(Hz): | 20-20,000 | Max.SPL(dB)(1000HzTHD<1%): | 137dB SPL(0dB SPL=2X10-5Pa) |
| Power Requirements: | 48V DC | Matching Connector: | 3-pin XLR |
The ACCR01 is a small diaphragm FET condenser microphone which was designed especially for government. lt is a small diaphragm condenser microphone with hyper-cardioid characteristic. The pickup pattern effectively minimized feedback problems and effectively rejects signals come of off-axis. lt also has Switchable low frequency roll-off and-10 dB pre-attenuation. Ultra low-noise transformerless FET circuitry eliminates low-frequency distortion, while a gold-plated 3-pin XLR connector assures the highest signal integrity. Typical applications include close miking of acoustic instruments or vocals, overhead miking of percussion instruments and voice pick up etc.
The microphone you purchased was inspected strictly by BJ797 Audio and be carefully put into a carry case. Please keep the case well. lt may protect your microphone during shipping. ltems below are included into the case:(quantity: 1 set)
| Items | Quantity |
| ACCR01 Condenser Microphone | 1 |
| QZ-23 Windscreen Foam | 1 |
| LJ-38 Collet | 1 |
| LX-91A Cable | 1 |
| JT-32 Table Stand | 1 |
| Instruction Manual | 1 |
| Certificate of Qualification | 1 |
| Warranty Card | 1 |
| Product | Small Diaphragm Condenser Microphone |
| Brand | 797AUDIO |
| Model | ACCR01 |
| Sensitivity(dB) at 1kHz | -38dB(0dB=1V/Pa,1kHz) |
| Polar Pattern | Cardioid |
| Frequency Range(Hz) | 20-20,000Hz |
| Output Impedance | Less than 200ohms |
| Max.SPL(1% THD@1000Hz,) | 137dB SPL(0dB SPL=2X10-5Pa |
| Equivalent Noise Level(dB) | 21dB-A |
| Power Requirements | 48V DC |
| Matching Connector | 3-pin XLR |
| Weight | 130g |
| Size | Φ21X135(mm) |
| Net Weight | 130g |
| Supply product | 797Audio brand, OEM, ODM |
| Delivery terms | By sea, By Express,By Air, By Train |
Interview, Live Chat, Recording, Broadcasting, Conference, Speech, Gaming,Singing, Entertainment,Etc.
Beijing 797 Audio Co.,Ltd. was founded in 1953 as an electric-acoustic manufacturer with long history in the field of microphone,speaker system,audio,etc.
Beijing 797 Audio Co., Ltd. has set microphone, speaker national standard, industry standard for audio, It covers audio products, public broadcasting and other fields. We already get over 70 patents on microphones and loudspeakers. We get ISO9001,ISO14001,ISO45001,and CE certificates, And our products have also been winning awards continuously.
